PGP® Ultra Rotary Sprinkler
This Upgrade of the First-Class PGP is Packed With New Features.

The PGP Ultra takes the foundation of the best-selling PGP Rotor and raises the bar with a variety of new features developed over three decades of research, customer feedback, and lab testing. Among the most notable improvements of the PGP Ultra is its non-strippable drive and automatic arc return.

These two features work to allow the turret to be turned without causing damage, and return the turret to its original arc regardless of where it is turned. Other advanced features include 22 nozzle options with several radius choices, and a headed slot and set screw. The diversity of the PGP Ultra offers system installers an array of efficient options on any site.

• Models: Shrub, 4", 12"
• Arc setting: 50 to 360 degrees
• Factory installed rubber cover
• Through-the-top arc adjustment
• Quick check arc mechanism
• Water lubricated gear-drive
• Nozzle choices: 34
• Nozzle racks: 1.5 to 8.0 Blue, 2.0 to 4.5 Low Angle Gray, 0.50 to 3.0 Black, 6.0 to 13.0 Green, MPR-25, MPR-30, MPR-35
• Warranty period: 5 years

	PGJ	PGP	PGP Ultra	I 20
QUICK SPECS
Radius	15' - 37'	22' - 52'	17' - 46'	17' - 46'
Flow Rate (GPM)	0.64 - 5.3	0.5 - 14.1	0.36 - 14.8	0.36 - 14.8
Inlet Size	1/2"	3/4"	3/4"	3/4"
FEATURES
Nozzle Options	8	27	34	34
Precipitation Rate (in/hr)	0.6	0.4	0.4	0.4
Recommended Pressure Range (PSI)	30 - 50	25 - 70	25 - 70	25 - 70
Operating Pressure Range (PSI)	20 - 100	20 - 100	20 - 100	20 - 100
Check Valves	Factory Option	Available	Factory Option	Pre-Installed
Specialty Nozzles	N/A	N/A	Factory Option	Pre-Installed
Check Height (ft.)	7'	4'	10'	10'
Factory-Installed Check Valve	Optional		Optional	10'
Warranty	2 Years	2 Years	5 Years	5 Years
ADVANCED FEATURES
Low Angle Nozzle Choices
Matched Precipitation Nozzles
Automatic Arc Return
Non-Strippable Drive
Part and Full Circle in One Model
Headed & Slotted Set Screw
Reclaimed Water ID
Available Short Radius Nozzles
Available Factory Installed Check Valve with up to 10' Elevation Change
FloStop Control
Stainless Steel Riser Option
Optional Pressure Regulated Body
Applications
Residential
Commercial/Municipalities
Athletic Fields
High Vandalism Areas
Low Pressure Areas
Riser-Mounted Sprinklers
Ground Cover and/or Shrubs
Reclaimed Water

I-20 Ultra Rotary Sprinkler
A High Performance Rotor with the Diversity and Efficiency for Any Site

With 22 nozzle choices, a 17’ to 46’ radius, and 6 body choices, the I-20 is an indispensable rotor. Whether you’ve got a small area, sandy soil, or a mix of shrubs and grass, the I-20 is ready to water with efficiency and reliability.

Recent improvements include automatic arc return; non-reversing 360, from 50 to 360 degrees; and a non-strippable, vandal-proof drive mechanism that prevents gear stripping and saves repair costs. Adding FloStop® control, easy through-the-top arc adjustment, and a standard drain-check valve all equate to a rotor that stands second-to-none in its class.

I-25 Ultra Performance Rotor
This Rugged Rotor Can Stand Up to Any Commercial Job

The I-25 gets the job done with power, efficiency, and commercial-grade reliability. With a robust watering radius of 40’ to 71’, this rotor can be used in a variety of applications and environments. Its compact, highly durable design comes with an optional stainless steel riser for tough-as-nails strength. With a 5-year warranty, the I-25 also has options for reclaimed water ID and high-speed.

A standard check valve is built in, and a wide selection of high performance nozzles are available. Efficient, tough, and built-to-last, Hunter’s I-25 rotors work hard day in and day out so you don't have to.

I-40 Ultra Performance Rotor
For Sports Fields and Parks, I-40 Delivers Professional Results

The I-40 is a tough commercial rotor that delivers water with accuracy and efficiency at distances up to 70 feet. Featuring diverse three-port nozzle options, a non-strippable drive, and a thick rubber cover built to prevent injury; it's no wonder this rotor is found in more stadiums than any other in the world.

With the strength of stainless steel, the I-40 is built to last in the harshest sports, public park, and commercial environments. If efficiency, effective irrigation, and beautiful results are the goal, the I-40 is the irrigation professional's best solution.
